Bari U.S. Stone Linear

BARI U.S. STONE LINEAR is available in 4 colors: SaltSunray, Clay and Road.
Available Sizes: 24”x24” Rectified, 12”x24” Rectified and 6”x24” Rectified.
Available Finish: Matte.
Available Thickness: 9mm.
Available Decors: Mosaic.
Available Special Pieces: Bullnose and Cove Base.
⇒ MADE IN USA

Bari U.S. Stone Linear Brochure

Print Friendly, PDF & Email

Availability: See product page for availability
SKU: n/a.

Request a Sample

Clear selection

Color Availability.

Salt

Sunray

Clay

Road

Decors.

Mosaic 12”x12” (2”x2” Pcs.)

Salt

Sunray

Clay

Road

Product photography and samples are to be used as a general guide. Color as well as percentage, size and shape of markings will vary. Sizes are nominal, not actual.

Size Availability

24”x24” Rectified

12”x24” Rectified

6”x24” Rectified

SIZETHICKNESSFINISHCOLORS
24”x24” Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road
12”x24” Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road
6”x24” Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road

Decors

SIZETHICKNESSFINISHCOLORS
Mosaic 12”x12” (2”x2” Pcs.) Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road

Special Pieces

Bullnose 3”x24” Rectified

Cove Base 6”x12” Rectified

PIECESSIZETHICKNESSFINISHCOLORS
Bullnose3”x24” Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road
Cove Base6”x12” Rectified9mm (3/8”)MatteSalt/Sunray/Clay/Road

TECHNICAL INFORMATION

Classification in accordance with ANSI A137.1: 2012 (P1 Class).

TECHNICAL FEATUREASTM TESTREQUIRED VALUEAVERAGE VALUE
Facial dimensionASTM C499±0.25% or ± 0.03 inIn accordance to ANSI A 137.1-2012
ThicknessASTM C499RANGE: 0.040 inch max (1 mm)In accordance to ANSI A 137.1-2012
WedgingASTM C502±0.25% or ± 0.03 inIn accordance to ANSI A 137.1-2012
Warpage diagonalASTM C485± 0.4% or ± 0.07 inIn accordance to ANSI A 137.1-2012
Warpage edgeASTM C485± 0.4% or ± 0.05 inIn accordance to ANSI A 137.1-2012
Water absorptionASTM C373≤ 0.5%Passed “impervious tiles” Class P1
Breaking strengthASTM C648≥ 250 lbs (>=1113 N)≥ 400 lbs
Freeze thawASTM C1026No damagesIn accordance
Chemical resistanceASTM C650As reportedUnaffected
MOHS hardness--Coeff. 6
D.C.O.F.BOT 3000≥ 0.42 WetMatte: ≥ 0.42 Wet

Average values referred to the last two years of production and related to the matte finish of the product.

Values relate to the matt finish of the product and to tests carried out by certified external laboratories, whose results are available upon request. Be sure to use the same caliber tiles.

Color reproductions may vary from actual products.

*Due to the intrinsic nature of porcelain stoneware tiles, please note that the coefficient of friction may vary within the same production lot or from one production lot to the other.

Products can become slippery when wet. We recommend to always keep the surface dry.

PACKAGING

SIZEMMPCS/BOXSQF/BOXSQM/BOXLBS/BOXKG/BOXBOX/PALSQF/PALSQM/PALLBS/PALKG/PAL
24"×24"610×610311.621.0847.6221.64046543.21904.77864
12"×24"305×610713.561.2655.5525.240542.5150.422221008
6"×24"152×610109.690.939.681840387.5361587.3720

Colored-Body Porcelain Stoneware – Rectified, One Caliber.
Shade Variation V2

MADE IN USA

Made In USA Icon
Application

Floor Tile, Wall Tile

Colors

Clay, Salt, Sunray, Road

Tile Size

Bullnose 3″x24″ Rectified, Mosaic 12″x12″ Rectified (2″x2″ Pieces), Cove Base 6″x12″ Rectified, 6″x24″ Rectified, 12″x24″ Rectified, 24″x24″ Rectified

Finish

Matte

Thickness

9mm
